Code: CALEX-0090
Caltech Technologies stockist of CALEX-0090, 20A Version, Ex Safety Switches. A complete range of Hazardous Area Products is available online & in-store.
€512.50 ex VAT
In Stock
QtyAdd to Cart
CALEX-0090 | 20A Version
Ex Safety Switches | Hazardous Area Products
Features:
- Marking accd. to 2014/34/EU D II 2 G Ex ed ia IIC T6 / D II 2 D Ex tD A21 IP66 T80 °C
- EC-Type Examination Certificate PTB 99 ATEX 1161
- IECEx Certificate of Conformity BKI 07.0012
- Marking accd. to IECEx Ex ed ia IIC T6
- Ex tD A21 IP66 T55 °C
- Permissible ambient temperature: –20 °C up to +40 °C1)
- Rated voltage: up to max. 690 V
- Rated current: max. 20 A
- Frequency 50/60 Hz
- Rated making-/rated breaking capacity AC-3
- accd. EN 60947-3
- Ue 230 V / Ie 20 A
- Ue 400 V / Ie 20 A
- Ue 500 V / Ie 16 A
- Ue 690 V / Ie 10 A
- Rated making-/ breaking capacity DC 1/DC 23
- accd. EN 60947-3
- Ue 60 V / Ie 20 A (1 contact)
- Ue 120 V / Ie 20 A (2 contacts in series)
- Rated making-/ breaking capacity DC-13 (L/R = 100 ms)
- accd. EN 60947-3
- Ue 60 V / Ie 6 A
- Switch-disconnector for maintenance
- accd. to IEC 62262-1
- Class 1
For more information about our products, please contact us.
